10 ways to fill a garage opening
Each day, every week, all year round we get asked the same question at all of our branches – How much is a standard garage door? There really is no such door anymore, only stock sizes for new build garages. With advances in garage door types, construction methods and operating mechanisms over the last 15 years you can buy a garage door to provide a lot more than just a steel panel in a timber frame. The choice of garage doors now is enormous with manufacturers catering for insulated doors, vertically rising doors, horizontally sliding doors and even garage doors with doors built in for easy pedestrian access. Below are 10 examples to show how 1 garage opening size can give 10 very different drivethrough measurements and 10 very different prices. The size is taken from the most frequently encountered brickwork size measured by our company over the last 20 years. I hope this helps!
The brickwork opening size most encountered on single brick built garage openings is 2290mm wide (approx. 7’6”) x 2250mm high (approx. 7’4 3/4”). We assume for the examples below that there is sufficient headroom and sideroom internally. The prices are based on removing the old garage door and gear and disposing from site and the installation of a new sub frame, the garage door and operating mechanism, and remote control electric operator where included. The examples are arranged by lowest price example first.
Example 1
| Door Type: |
Up and Over (canopy type) |
| Installation position: |
Inbetween structural opening |
| Operation: |
Manual |
| Material: |
Galvanised steel |
| Door panel: |
Single skin - uninsulated |
| Door design: |
Horizontal Ribbed (click for picture) |
| Colour: |
White or Brown factory powdercoated |
| Sub Frame: |
Box section steel matching door panel colour |
|
Ordering Size:
|
2134 x 2134 (7’ x 7’) (standard size) |
| Extras included: |
Upvc infill fascia above door head frame to seal small gap as total door height including frame is 2192. |
| |
Total Price £580 including VAT |
Example 2
| Door Type: |
Roller Shutter |
Installation position: |
Behind structural opening |
| Operation: |
Manual |
| Material: |
Galvanised steel |
| Door panel: |
Single skin - uninsulated |
| Door design: |
Horizontal Ribbed |
| Colour: |
Choice of 12 plastisol or powdercoated colours |
| Sub Frame: |
None – direct fix to structural opening |
| Ordering Size: |
2286 x 2200 (7’6” x 7’2 ½”) (standard size) |
Extras included: |
None required |
| |
Total price £645 including VAT |
Example 3
| Door Type: |
Up and Over (canopy type) |
| Installation position: |
Behind structural opening |
| Operation: |
Manual |
| Material: |
Galvanised steel |
| Door panel: |
Single skin - uninsulated |
| Door design: |
Georgian panelled (9 or 12 panels) |
| Colour: |
White or Brown factory powdercoated |
| Sub Frame: |
Box section steel matching door panel colour |
Ordering Size: |
2261 x 2134 (7’5” x 7’0”) (standard size) |
| Extras included: |
Upvc infill fascia above door head frame to seal small gap as total door height including frame is 2192. |
| |
Total price £700 including VAT |
Example 4
| Door Type: |
Side Hinged |
| Installation position: |
Inbetween structural opening |
| Operation: |
Manual |
| Material: |
Galvanised steel |
| Door panel: |
Single skin - uninsulated |
| Door design: |
Vertical Ribbed |
| Colour: |
White or Brown factory powdercoated |
| Sub Frame: |
Box section steel matching door panel colour |
| Ordering Size: |
2134 x 2134 (7’ x 7’) (standard size) |
| Extras included: |
Upvc infill fascia above and to sides of frame to seal small gap as overall door and fixing frame size is smaller than structural opening. |
| |
Total price £850 including VAT |
Example 5
| Door Type: |
Sectional Overhead |
| Installation position: |
Behind structural opening |
| Operation: |
Manual |
| Material: |
Galvanised steel |
| Door panel: |
Double Skin 20mm - Insulated |
| Door design: |
Georgian Panelled |
| Colour: |
White or Brown factory powdercoated |
| Sub Frame: |
Box section steel matching door panel colour |
| Ordering Size: |
2286 x 2125 (7’6” x 7’0”) (standard size) |
| Extras included: |
Upvc infill fascia above head frame - door has weatherseals in the door frame and bottom seal as standard. |
| |
Total price £1,050 including VAT |
Example 6
| Door Type: |
Up and Over (retractable type) |
| Installation position: |
Inbetween structural opening |
| Operation: |
Remote Control – Electric operated |
| Material: |
Galvanised steel |
| Door panel: |
Single skin - uninsulated |
| Door design: |
Vertical Ribbed |
| Colour: |
White or Brown factory powdercoated |
| Sub Frame: |
Box section steel matching door panel colour |
Ordering Size: |
2134 x 2134 (7’ x 7’) (standard size) |
| Extras included: |
Upvc infill fascia above door head frame to seal small gap as total door height including frame is 2192. |
| |
Total price £1,250 including VAT |
Example 7
| Door Type: |
Roller shutter |
| Installation position: |
Behind structural opening |
| Operation: |
Remote Control – Electric operated |
| Material: |
Aluminium |
| Door panel: |
Double skin - insulated |
| Door design: |
Horizontal ribbed (click for feature) |
| Colour: |
15 standard colours and 3 woodgrain laminates. |
| Sub Frame: |
Aluminium guides powdercoated coloured |
| Ordering Size: |
2290 x 2250 (7’6 x 7’4 ½”) (purpose made) |
| Extras included: |
Two hand held ‘rolling code’ transmitters,manual override, safety edge bottom seal and courtesy internal light and control box. |
| |
Total price £1,450 including VAT |
Example 8
| Door Type: |
Sectional Overhead |
| Installation position: |
Behind structural opening |
| Operation: |
Remote Control – Electric operated |
| Material: |
Galvanised steel |
| Door panel: |
Double skin - insulated |
| Door design: |
Georgian panelled |
| Colour: |
White or dark brown powdercoat |
| Sub Frame: |
Box section steel matching door panel colour. |
| Ordering Size: |
2286 x 2125 (7’6” x 7’0”) (standard size) |
| Extras included: |
Upvc infill fascia above head frame - door has weatherseals in the fixing frame and bottom seal as standard. 2 hand held transmitters and manual override. |
| |
Total price £1,550 including VAT |
Example 9
| Door Type: |
Side Hinged |
| Installation position: |
Inbetween structural opening |
| Operation: |
Remote Control – Electric operated |
| Material: |
Timber - Cedarwood |
| Door panel: |
Single skin - insulated |
| Door design: |
Traditional vertical boarded |
| Colour: |
Choice of factory finished Sikkens microporous treatments |
| Sub Frame: |
Timber – white primed or basecoat stained softwood 70 x 70 PSE |
Ordering Size: |
2134 x 2125 (7’0” x 7’0”) (standard size) |
| Extras included: |
2 hand held transmitters and manual override system. |
| |
Total price £1,800 including VAT |
Example 10
| Door Type: |
Silvelox |
| Installation position: |
Behind structural opening |
| Operation: |
Remote Control – Electric operated |
| Material: |
Timber - Okoume |
| Door panel: |
Double skinned 80mm Insulated |
| Door design: |
VIP or DOC (click for feature) |
| Colour: |
Choice of factory finished treatments |
| Sub Frame: |
Steel with matching timber fascia covers |
| Ordering Size: |
2250 x 2130 (7’4 ½” x 7’0”) (purpose made) |
| Extras included: |
Extras included: 2 hand held transmitters, safety beams x 2, manual override facility, fully weathersealed and central pedestrian door option. |
| |
Total price £3800 including VAT |
