Carteck Insulated Side Hinged

carteck side hinged insulated steel doorsCarteck Insulated Steel Side Hinged Doors

There are many reasons for installing insulated garage doors and the side hinged type would offer you the very best in convenience if you were using the garage as a workshop, office, gym, playroom or some other use. Being able to open and close one leaf only but once closed maintain excellent insulation levels as well as security would be ideal and the doors are fully sealed all around the sides and top with the integral sub frame system used.For the very best in panel strength, security and insulation look no further than the superb insulated steel side hinged garage door range from market leaders Carteck (or Teckentrup in Germany).

Carteck are not usually known for hinged doors but more for their superb sectional garage door range, the door panels used for the side hinged doors are derived from the insulated double skinned steel panels of the sectional garage doors. In Germany the Teckentrup manufacturing plant produce many different types of side hinged doors and the Carteck side hinged range has been developed specifically for the UK garage market.

insulated hinged garage doors with windows
Why Insulated Side Hinged?

Most people buying side hinged garage doors do so as they use their garage for other purposes other than storing a car and this can be as a workshop, games room, gym, office or simple a store for bikes and all the other daily items we tend to have. Access to these items may be frequent and many times the garage has direct access to the main house from an internal door so security is very important as well as the benefits of high levels of insulation.

Design Choices

The Carteck side hinged doors are available in 8 different panel designs with each design having options available for a woodgrain embossed surface, stucco or micrograin surface finish for the finer details of visual appearance.

All designs can have a 50/50 or 1/3rd and 2/3rd option to offer a smaller pedestrian door for easier access, the only one that cannot be offered is the Georgian design with the taller, vertical panels as the design is restrictive.

Insulated Steel Side Hinged Door Designs

Standard Ribbed Vertical

Centre Ribbed Vertical

Solid Ribbed Vertical

Standard Ribbed Horizontal

Centre Ribbed Horizontal

Solid Ribbed Horizontal

Solid 40mm Thick Panels

The Carteck side hinged doors are constructed from 40mm thick interlocking foam filled galvanised steel panels that also provide excellent sound reduction and incredible strength.

The mitred door leaf and door frame are finished in a matching finish from white, Trend and RAL colours as well as woodgrain effect laminate finishes. The door panels are always RAL 9002 off white to the inside face for maximum light enhancement and practical purposes.

The inside face of the door panels are also very easy to keep clean and have no unsightly bracing bars and locking mechanisms unlike single skin steel and timber constructed door panels.

get a quote on insulated side hinged garage doors

Fixing Frame

All these side hinged doors are factory fitted with a fully finished aluminium fixing sub frame to make installation easy and precise on site only rewquiring the door and frame to be positioned into place, squared and secured.

The doors are all made to order to ensure a perfect fit and maximise the width and height of your garage opening

The frame is finished in the same colour as the door panel colour chosen and in the case of the laminate woodgrain panels a complimentary RAL colour is used for the framework.

inside picture of the insulated carteck side hinged door
Inside view of Carteck side hinged doors
outside image of side hinged doors
Outside view of Carteck side hinged doors

High Quality Features as Standard

stainless steel handle and double throw deadbolt High grade stainless steel handles and lock covers are standard and offer a tough attractive finish to the overall visual appearance.
The double deadbolt locking is extra secure and the locking mechanism is situated behind a tough cover strip fitted on the leading door panel.
steel hinges for extra stabiltiy High quality aluminium hinges are fitted as standard with secured hinge bolts making it extremely difficult to attempt to lever the door open.
Easy adjustments are possible for fine tuning the door leaf operation.
2 or 3 hinges are fitted to each leaf depending on the door size ordered.
frame seals and door seals standard Double seals and mitred corners make the Carteck side hinged doors exceptionally draught and rain proof.
In addition to a seal on every edge of the door panel there is also rubber sealing to the aluminium fixing sub frame
flush bolt security The inactive garage door leaf is secured with flush fitting bolts to the top and bottom and at the bottom is further enhanced with the standard feature of a rot proof floor seal and threshold to further increase the sealing properties and security of this door.
standard door stays Door stays are fitted as standard protecting your door panels from slamming closed or flying open on windy days and smashing into objects or your car.
These door stays are top grade spring dampened with easy adjustment.
They are desinged to hold the door panel open at 90 degrees.

 get a quote on insulated side hinged garage doors

Finished Colours

The Carteck side hinged doors are available in the optional standard paint colours shown below for a small extra charge and also in Golden Oak, Rosewood and Dark Oak laminate finishes which match very well with Upvc windows using the same finishes. White (RAL9016) is the factory standard and off white (RAL9002) inside.

Dark Oak

Golden Oak

Flame Red
RAL 3000
Jet Black
Moss Green
Fir Green
Anthracite Grey
Light Grey
Window Grey
Sepia Brown
Grey Aluminium
Cream White
White Aluminium
Steel Blue
Quartz Grey
woodgrain surface finish
smooth surface finish

micro profile surface finish
Micro Profile

stucco surface finish

Window Options

There are a choice of scratch proof, easy clean window options for any of the designs available and they are all double sealed units to maintain the insulation and strength offered by the main door panel. Round as well as square windows are available for the solid panel door designs.

Side hinged insulated doors with windows

Georgian 50/50 split doors fitted with double glazed units and Georgian glazing bars all in white.
